| Brand |
Gigabyte |
| Model |
Z790 D AX |
| Colour |
Black |
| CPU |
LGA1700 socket: Support for the 14th, 13th, and 12th Generation Intel® Core™, Pentium® Gold and Celeron® Processors |
| |
(Check GIGABYTE’s website for the latest CPU support list.) |
| |
L3 cache varies with CPU |
| Chipset |
Intel® Z790 Express Chipset |
| Memory |
14th and 13th Generation Intel® Core™ i9/i7 Processors: |
| |
– Support for DDR5 7600(O.C.) /7400(O.C.) /7200(O.C.) /7000(O.C.) /6800(O.C.) /6600(O.C.) / 6400(O.C.) / 6200(O.C.) / 6000(O.C.) / 5800(O.C.) / 5600 / 5400 / 5200/ 4800/4400 MT/s memory modules |
| |
13th Generation Intel® Core™ i5/i3 and 12th Generation Intel® Core™, Pentium® Gold and Celeron® Processors: |
| |
– Support for DDR5 4800/4400 MT/s memory modules |
| |
4 x DDR5 DIMM sockets supporting up to 192 GB (48 GB single DIMM capacity) of system memory |
| |
Dual-channel memory architecture |
| |
Support for ECC Un-buffered DIMM 1Rx8/2Rx8 memory modules (operate in non-ECC mode) |
| |
Support for non-ECC Un-buffered DIMM 1Rx8/2Rx8/1Rx16 memory modules |
| |
Support for Extreme Memory Profile (XMP) memory modules |
| |
(Refer to “Memory Support List” on GIGABYTE’s website for detailed information.) |
| Onboard Graphics |
Integrated Graphics Processor-Intel® HD Graphics support: |
| |
– 1 x HDMI port, supporting a maximum resolution of 4096×2160@60 Hz |
| |
– 1 x DisplayPort, supporting a maximum resolution of 4096×2304@60 Hz |
| Audio |
Realtek® Audio CODEC |
| |
High Definition Audio |
| |
2/4/5.1/7.1-channel audio |
| LAN |
Realtek® 2.5GbE LAN chip (2.5 Gbps/1 Gbps/100 Mbps) |
| Wireless Communication |
Intel® Wi-Fi 6E AX211 (PCB rev. 1.0) |
| |
– WIFI a, b, g, n, ac, ax, supporting 2.4/5/6 GHz carrier frequency bands |
| |
– BLUETOOTH 5.3 |
| Expansion Slots |
CPU: |
| |
– 1 x PCI Express x16 slot, supporting PCIe 5.0 and running at x16 (PCIEX16) |
| |
Chipset: |
| |
– 1 x PCI Express x16 slot, supporting PCIe 4.0 and running at x4 (PCIEX4) |
| |
– 1 x PCI Express x16 slot, supporting PCIe 3.0 and running at x1 (PCIEX1_4) |
| |
– 2 x PCI Express x1 slots, supporting PCIe 3.0 and running at x1 (PCIEX1_2, PCIEX1_3) |
| Storage Interface |
CPU: |
| |
– 1 x M.2 connector (Socket 3, M key, type 22110/2280 PCIe 4.0 x4/x2 SSD support) (M2A_CPU) |
| |
Chipset: |
| |
– 1 x M.2 connectors (Socket 3, M key, type 2280 PCIe 4.0 x4/x2 SSD support) (M2P_SB) |
| |
– 1 x M.2 connectors (Socket 3, M key, type 2280 SATA and PCIe 4.0 x4/x2 SSD support) (M2M_SB) |
| |
– 4 x SATA 6Gb/s connectors |
| USB |
Chipset: |
| |
– 1 x USB Type-C® port on the back panel, with USB 3.2 Gen 2 support |
| |
– 1 x USB Type-C® port with USB 3.2 Gen 1 support, available through the internal USB header |
| |
– 1 x USB 3.2 Gen 2 Type-A port (red) on the back panel |
| |
– 6 x USB 3.2 Gen 1 ports (4 ports on the back panel, 2 ports available through the internal USB header) |
| |
– 2 x USB 2.0/1.1 ports on the back panel |
| |
Chipset+USB 2.0 Hub: |
| |
– 4 x USB 2.0/1.1 ports, available through the internal USB headers |
| Internal I/O Connectors |
Various connectors for power, fans, LEDs, audio, USB, etc. |
| Back Panel Connectors |
Various ports including USB, audio, HDMI, DisplayPort, LAN, etc. |
| I/O Controller |
iTE® I/O Controller Chip |
| H/W Monitoring |
Voltage, temperature, fan speed, water cooling flow rate detection, fan fail warning, fan speed control |
| BIOS |
1 x 256 Mbit flash, AMI UEFI BIOS |
| Unique Features |
Support for GIGABYTE Control Center (GCC), Q-Flash, Q-Flash Plus, Smart Backup |
| Bundled Software |
Norton® Internet Security (OEM version), LAN bandwidth management software |
| Operating System |
Support for Windows 11 64-bit, Windows 10 64-bit |
| Form Factor |
ATX Form Factor; 30.5cm x 24.4cm |
| Warranty |
3 Years |
| Note |
*Features, Price and Specifications are subject to change without notice. |
