Support Intel Core Ultra Processors (Series 2) for LGA 1851 socket
Supports DDR5 Memory, Dual Channel DDR5 9200+ MT/s (OC)
Ultra Performance: 14+1+1+1 Duet Rail Power System 55A DrMOS, dual 8-pin CPU power connectors, Core Boost, Memory Boost, 6-layer PCB made by 2oz thickened copper and server-grade level material
Frozr Guard: Extended Heatsink, MOSFET thermal pads rated for 7W/mK, additional choke thermal pads and EZ M.2 Shield Frozr II are built for high performance system and non-stop experience
EZ DIY: EZ M.2 Shield Frozr II, EZ M.2 Clip II, EZ PCIe Clip II and EZ Antenna
Lightning Fast Game experience: PCIe 5.0 slot, Lightning Gen 5 x4 M.2
Ultra Connect: Thunderbolt™ 4 port, 5G LAN with Intel Wi-Fi 7 Solution - the latest solution for professional and multimedia use, delivering secure, stable, and high-speed networking and data transmission
|
Brand |
MSI |
|
Modle |
PRO Z890-P WIFI |
|
Platform |
INTEL |
|
Socket |
LGA1851 |
|
Cpu Type |
Core Ultra |
|
Chipset |
Z890 |
|
Memory Speed |
up to 9200+ |
|
Max Memory Support |
256 GB |
|
Supported Memory Type |
DDR5 |
|
Channel Supported |
Dual Channel |
|
Memory Feature |
Supports Intel® POR Speed and JEDEC Speed |
|
Supports Memory Overclocking and Intel® XMP 3.0 |
|
|
Supports Non-ECC, Un-buffered memory |
|
|
Supports CUDIMM |
|
|
Graphics Port |
1x HDMI,1x DisplayPort,1x Type-C DisplayPort |
|
Expansion Slots |
3x PCI-E x16 slot |
|
1x PCI-E x1 slot |
|
|
PCI_E1 Gen PCIe 5.0 supports up to x16 (From CPU) |
|
|
PCI_E2 Gen PCIe 4.0 supports up to x1 (From Chipset) |
|
|
PCI_E3 Gen PCIe 4.0 supports up to x4 (From Chipset) |
|
|
PCI_E4 Gen PCIe 4.0 supports up to x4 (From Chipset) |
|
|
Wireless Networking |
Wi-Fi 7,Bluetooth 5.4 |
|
Back Panel I/O Ports |
DisplayPort |
|
Mouse / Keyboard |
|
|
USB 2.0 |
|
|
5G LAN |
|
|
Wi-Fi / Bluetooth |
|
|
Audio Connectors |
|
|
Flash BIOS Button |
|
|
Thunderbolt™ 4 40Gbps (Type-C) |
|
|
HDMI™ |
|
|
USB 2.0 |
|
|
USB 5Gbps Type-A |
|
|
USB 10Gbps Type-C |
|
|
USB 10Gbps Type-A |
|
|
Internal I/O Connector |
1x Power Connector(ATX_PWR) |
|
2x Power Connector(CPU_PWR) |
|
|
1x Power Connector(PCIE_PWR 8pin) |
|
|
1x CPU Fan |
|
|
1x Combo Fan (Pump_Sys Fan) |
|
|
5x System Fan |
|
|
1x EZ Conn-header (JAF_1) |
|
|
2x Front Panel (JFP) |
|
|
1x Chassis Intrusion (JCI) |
|
|
1x Front Audio (JAUD) |
|
|
1x Tuning Controller connector(JDASH) |
|
|
3x Addressable V2 RGB LED connector (JARGB_V2) |
|
|
1x RGB LED connector(JRGB) |
|
|
1x TPM pin header(Support TPM 2.0) |
|
|
4x USB 2.0 ports |
|
|
4x USB 5Gbps Type A ports |
|
|
1x USB 20Gbps Type C ports |
|
|
Form Factor |
ATX |
|
Warranty |
3 Years |
|
Note |
Features, Price, Specifications are subject to change without notice. |
