Gigabyte X870E Aorus Master DDR5 Motherboard

Name: Gigabyte X870E Aorus Master DDR5 Motherboard - The IT Gear
SKU: X870E AORUS MASTER
Price: 47049.00 INR
Availability: InStock

SKU: X870E AORUS MASTER

Apple Shopping Event

Hurry and get discounts on all Apple devices up to 20%

Sale_coupon_15

Original price was: ₹140,999.00.Current price is: ₹47,049.00.

In stock

Click here for Any Query

In stock

Add to compare

Payment Methods:

114 People watching this product now!

Similar Products

Gigabyte B760M DS3H DDR5 Motherboard

Rated 0 out of 5

GIGABYTE

NZXT N7 Z490 Atx Intel Chipset Motherboard Wi-Fi White

NZXT N7 Z490 ATX Wi-Fi DDR4 Intel Chipset Motherboard – White

Rated 0 out of 5

NZXT

Gigabyte X870E Aorus Master DDR5 Motherboard

FEATURES

Gigabyte DDR5 OC up to 8600MT/s.
AMD Socket AM5 : Supports AMD Ryzen™ 9000 / 8000 / 7000 Series Processors.
Digital twin 16+2+2 phases VRM solution.
Dual Channel DDR5 : 4*DIMMs with AMD EXPO™Memory Module Support.
DDR Wind Blade : Enhanced Active Cooling for Memory Modules.
M.2 EZ-Match : Magnetic alignment for easy installation of large heatsinks.
WIFI EZ-Plug : Quick and easy design for Wi-Fi antenna installation.
EZ-Latch Plus : PCIe and M.2 slots with Quick Release & Screwless Design.
EZ-Latch Click : M.2 heatsinks with screwless design.
Sensor Panel Link : Onboard video port for hassle-free in-chassis panel setup.
Friendly UI: Multi-Theme, AIO Fan Control, and Q-Flash Auto Scan in BIOS and SW..
New Power Monitor in HWinfo for real-time monitoring on CPU power phases.
Ultra-Fast Storage : 4*M.2 slots, including 3* PCIe 5.0 x4.
Efficient Thermal : VRM Thermal Armor Advanced with I/O ZONE AORUS LIGHTING & M.2 Thermal Guard XL.
Fast Networking : 5GbE LAN & Wi-Fi 7 with directional Ultra-high gain antenna.
Extended Connectivity : Dual USB4 Type-C with DP-Alt, HDMI.
Reliable Audio : Realtek ALC1220 HD Audio & WIMA Audiophile Grade Capacitors.
Ultra Durable PCIe Armor : The metal back plate of PCIe x16 slot for enhanced durability..
PCIe UD Slot X : PCIe 5.0 x16 slot with 10X strength for graphics card.

SPECIFICATIONS

Brand+A1:A1:B35	Gigabyte
Model	X870E AORUS MASTER
Colour	Black
Chipset	AMD X870E
CPU Socket	AM5
Back Panel I/O
USB	2x USB-A (USB 2.0) 4x USB-A (USB 3.0 / 3.1/3.2 Gen 1) 4x USB-A (USB 3.1/3.2 Gen 2) 2x USB-C (USB4)
Thunderbolt	No
Display	1x HDMI
Audio	2x 1/8″ / 3.5 mm 1x S/PDIF
Ethernet / Controller	1x Realtek 5GbE
Wi-Fi Antenna	2x Connector
Buttons	BIOS Flashback, Clear CMOS
Memory
Memory Slots	4x 288-Pin
Memory Support	DDR5 4400, 4800, 5200, 5600, 6000, 6200, 6400, 6600, 6666, 6800, 7000, 7200, 7600, 7800, 8000, 8200, 8400, 8600 MT/s
Maximum Capacity	256 GB
Channel Architecture	Dual Channel
ECC Support	Non-ECC, ECC Unbuffered
Storage Expansion
SATA	4x SATA III
Storage Slots	1x M.2 (M Key) 2280, 22110, 2580, 25110 (PCIe 5.0 x4) 2x M.2 (M Key) 2280, 22110 (PCIe 5.0 x4) 1x M.2 (M Key) 2280, 22110 (PCIe 4.0 x4, PCIe 4.0 x2)
Optane Memory Support	No
RAID Support	RAID 0, 1, 5, 10 (M.2) RAID 0, 1, 10 (SATA)
Internal I/O
Expansion Slots	1x PCIe 5.0 x16 1x PCIe 4.0 x16 (x4 mode) 1x PCIe 3.0 x16 (x4 mode)
USB	2x USB 2.0 Header (Supports 4 USB-A Port) 2x USB 3.0 / 3.1/3.2 Gen 1 Header (Supports 4 USB-A Port) 1x USB 3.2 Gen 2×2 Header (Supports 1 USB-C Port)
Air Cooling	1x 4-Pin CPU 4x 4-Pin System
Liquid Cooling	3x 4-Pin Pump
Power Connectors	1x 24-Pin Mainboard 2x 8-Pin ATX
Security	TPM Header
LED Header	5x RGB
Diagnostics	Clear CMOS, Flash BIOS
BIOS
ROM	256 Mb
Front Panel I/O
Front Panel I/O	AAFP
Audio
Audio Codec	Realtek ALC1220 (7.1-Channel)
DAC	No
Wireless
Wi-Fi	Wi-Fi 7 (802.11be); Tri-Band (2.4, 5, & 6 GHz)
Bluetooth	5.3
Software
OS Compatibility	Windows 11 (64-Bit Only)
Physical
Form Factor	ATX
Dimensions	12.0 x 9.6″ / 30.5 x 24.4 cm
Packaging Info
Package Weight	5.69 lb
Box Dimensions (LxWxH)	14.1 x 11.7 x 3.3″
Warranty	3 Years
Note	*Features, Price and Specifications are subject to change without notice.
