Vibrant LCD Display for real-time system monitoring and personalized visuals
Efficient 240mm Radiator designed for superior heat dissipation
Upgraded Dual-Chamber Pump for improved cooling performance and reliability
Dual ARGB Fans with customizable lighting effects and silent operation
Optimized Airflow Design to ensure stable temperatures during heavy workloads
Durable Tubing & Build Quality for long-lasting performance
Wide Compatibility with Intel and AMD CPU sockets
|
Brand |
Cooler Master |
|
Product Number |
MLX-D24M-A25SZ-L1 |
|
Colour |
Black |
|
CPU Socket |
Intel LGA 1851 / 1700 / 1200 / 1150 / 1151 / 1155 / 1156 |
|
CPU Socket |
AMD AM5 / AM4 |
|
Radiator Material |
Aluminum |
|
Radiator Dimensions |
(240) – 277 x 119.2 x 27 mm (10.9 x 4.7 x 1.1 inch) |
|
Pump Dimensions |
92.5 x 87 x 38.5 mm (3.6 x 3.4 x 1.5 inch) |
|
Pump Profiles |
Addressable Gen2 RGB |
|
Pump Speed |
3400 ± 300 RPM |
|
Pump MTTF |
210,000 Hours |
|
Pump Noise Level |
25 dBA (Max) |
|
Pump Rated Voltage |
12 VDC |
|
Pump Power Consumption |
3.84W |
|
Pump Connector |
3-Pin ARGB + 4-Pin PWM |
|
Tube Length |
350 mm |
|
Fan Dimensions (LxWxH) |
241 x 122 x 26.5 mm (9.5 x 4.8 x 1 inch) |
|
Profile |
Addressable Gen 2 RGB |
|
Fan Quantity |
1 PC |
|
Fan Speed |
690 ~ 2500 RPM ± 15% |
|
Fan Airflow |
240.35 m³/h (141.4 CFM) |
|
Fan Air Pressure |
3.61 mmH2O |
|
Fan MTTF |
160,000 Hours |
|
Fan Nouse Level |
36 dB(A) |
|
Fan Bearing Type |
Loop Dynamic Bearing |
|
Fan Connector |
7-Pin PWM + ARGB |
|
Fan Rated Voltage |
12 VDC |
|
Fan Rated Current |
0.5A |
|
Fan Safety Current |
0.8A |
|
Fan Power Consumption |
6 W |
|
Radiator Size |
240 |
|
Cooler Type |
Liquid Cooler |
|
Series |
MasterLiquid |
|
LCD Exterior Color |
Black |
|
LCD Dimensions |
85 x 79.2 x 18.7 mm (3.4 x 3.1 x 0.7 inch) |
|
LCD Connector |
USB Type-C to Motherboard 9 pin |
|
LCD Screen Size |
2.1 inches / Diameter 53.3 mm |
|
LCD Screen Resolution |
480 x 480 Px |
|
LCD Screen Luminance |
300 cd/m² |
|
LCD Screen Refresh Rate |
60Hz |
|
LCD Screen Orientation |
Software-MasterCtrl adjustable |
|
LCD Rated Voltage |
5 VDC |
|
LCD Rated Current |
0.3 A |
|
LCD Safety Current |
0.5 A |
|
LCD Power Consumption |
1.5W |
|
Warranty |
6 Years |
|
Note** |
**Prices, Specifications & Features are subject to change without notice |
