BUILD THE ECOSYSTEM YOU WANT
The Next Level Racing® GTElite Lite offers versatile upgrade options within the Elite series to meet the user’s evolving racing needs. For instance, with the purchase of the Next Level Racing® GTElite Motion Adaptor Kit*, the GTElite Lite becomes compatible with Next Level Racing’s existing and future motion products. Moreover, the GTElite Lite can transform into a Formula or Hybrid racing position cockpit. That is possible through the addition of the Next Level Racing GTElite Formula and Hybrid Pedal Upgrade Kit and the Next Level Racing Universal Seat Brackets*. Furthermore, with a growing ecosystem of accessories in the Elite series, users have the opportunity to create a full racing experience. They can do this by adding accessories like attachable Monitor Stands, keyboard and mouse trays, tablet mount holders, and VR holders.
*Items purchased separately
BUILT TO BE STRONG
Conventional corner brackets are now things of the past. In contrast, the GTElite Lite Cockpit utilizes an innovative approach with its 8mm thick Carbon Steel Reinforced Upright Direct Mounting plates. As a result, the GTElite Lite boasts stronger reinforcement and connection between the vertical uprights and the base of the chassis. Furthermore, to eliminate any movement and increase the clamping force between the components, custom-engineered full channel width spring ball T-slot nuts are strategically used throughout the build. Additionally, through bolts are employed in areas that require higher clamp force and rigidity. The 8mm Carbon Steel Sandwich Plate also provides a connection between the vertical uprights and the pedal plate to lock in and increase the reinforcement between the structural parts of the cockpit. Similarly, the strength continues with precision machined holes to bolt the base of the profile directly for a more rigid foundation.
TAKE CONTROL UNDER INTENSE RACING
Included in the GTElite Lite Front & Side Mount Edition are Next Level Racing’s bespoke Direct Drive mounting solution. Additionally, machine-folded and precision laser-cut parts make the Next Level Racing GTElite Lite Front & Side Mount Cockpit a premium aluminum option for racers. This is particularly important for those who demand the ultimate in versatility and rigidity from their cockpit.
Furthermore, the 8mm thick Carbon Steel Side Mounts offer 70 degrees of tilt (40 degrees downward, 30 degrees upward). As a result, this feature gives drivers the option to fine-tune their Elite cockpit for the perfect driving position. Notably, the GTElite Lite Front & Side Mount Edition also includes 6mm Carbon Steel (machine folded & laser cut) “WINGS” and the 6mm Front Mount Bracket Option.
Moreover, the strength of these components is evident in the FEA (Finite Element Analysis) Tests. Particularly, these tests compare the innovative GTElite Lite plate designs to other flat steel or aluminum designs commonly found in conventional cockpits on the market.
Pedal Deck – equivalent to 10.84mm steel or 15.83mm aluminum
Shifter Plate – equivalent to 18.51 steel or 29.18mm aluminum
Our custom Front & Side Mount is compatible with the best Direct Drive wheelbase brands on the market, full compatibility is below:
– Fanatec dd1/dd2 podium direct drive
– Simucube 2 Pro /Simucube 2 Sport/Simucube 2 Ultimate
– Simagic Alpha/M10
– Mige 130 motors
– VRS Directforce Pro
– Kollmorgen akm 52-53-54 (OSW and Leo Bodnar Simsteering systems)
FLEX-FREE NLR SEAT SLIDERS SYSTEM
The innovative Next Level Racing® Seat Sliding System has been meticulously designed and engineered, specifically to address and eliminate the issue of flex found in conventional seat sliders used in simulators. Then, the NLR ratchets are thoughtfully included, thereby allowing you to easily slide your seat back and forth. Consequently, this feature enables you to find the desired position, ensuring a flex-free racing experience.
|
Brand |
Next Level Racing |
|
Model |
NLR-E029 |
|
Product Type |
Aluminium sim racing cockpit frame |
|
Frame Material |
Premium black anodised aluminium with reinforced carbon steel mounting plates |
|
Mount Type |
Front & side direct mount brackets with ~70° tilt adjustability (40° down / 30° up) |
|
Seat Slider System |
NLR flex-free seat slider and brackets included |
|
Pedal Adjustability |
Height, angle & distance adjustable |
|
Extras Included |
Height-adjustable shock feet, Buttkicker Gamer 2 adapter, cable management clips, tool holder, custom end caps, magnetic spirit level |
|
Rigidity & Build |
Rigid profile with precision-machined holes and reinforced carbon steel parts |
|
User Height Range |
~120 – 210 cm (4 ft – 6 ft 9 in) |
|
Max Supported Weight |
~150 kg / 330 lbs |
|
Product Dimensions (L×W×H) |
~148 × 82.5 × 86.5 cm / ~58.3″ × 32.5″ × 34.1″ |
|
Product Weight |
~34 kg / ~74.9 lbs |
|
Box Dimensions |
~128.5 × 41 × 25.1 cm / ~50.6″ × 16.1″ × 9.9″ |
|
Boxed Weight |
~36.6 kg / ~80.7 lbs |
|
Compatibility |
Major wheels & pedals (e.g., Fanatec, Thrustmaster, Logitech, SimXperience) and Next Level Racing motion platforms & accessories |
|
Seat & Electronics |
Sold separately |
|
Warranty |
12 Months |
|
Note |
* Features, Price, Specifications are subject to change without notice. |
