Brand | TP-Link |
Model | SG2008 |
Color | Black |
Standards and Protocols | IEEE 802.3i, IEEE 802.3u, IEEE 802.3ab, |
IEEE 802.3ad, IEEE 802.3x, IEEE 802.1d, IEEE 802.1s, | |
IEEE 802.1w, IEEE 802.1q, IEEE 802.1p, IEEE 802.1x | |
Interface | 8 10/100/1000Mbps RJ45 Ports |
(Auto-Negotiation/Auto MDI/MDIX) | |
Network Media | 10BASE-T: UTP category 3, 4, 5 cable (maximum 100m) |
100BASE-TX/1000Base-T: UTP category 5, 5e or above cable | |
(maximum 100m) | |
Fan Quantity | Fanless |
Power Supply | 100~240VAC, 50/60Hz |
External Power Adapter(Output: 12VDC/1A) | |
Power Consumption | Maximum: 6.42W (220V/50Hz) |
Dimensions ( W x D x H ) | 8.2* 4.9* 1.0 in. (209* 126* 26mm) |
Bandwidth/Backplane | 16Gbps |
Packet Forwarding Rate | 11.9Mpps |
MAC Address Table | 8k |
Jumbo Frame | 9216 Bytes |
Quality of Service | Support 802.1p CoS/DSCP priority |
Support 4 priority queues | |
Queue scheduling: SP, WRR, SP+WRR | |
Port/Flow- based Rate Limiting | |
Voice VLAN | |
L2 Features | IGMP Snooping V1/V2/V3 |
802.3ad LACP (Up to 6 aggregation groups, | |
containing 4 ports per group) | |
Spanning Tree STP/RSTP/MSTP | |
BPDU Filtering/Guard | |
TC/Root Protect | |
Loop back detection | |
802.3x Flow Control | |
VLAN | Supports up to 512 VLANs simultaneously (out of 4K VLAN IDs) |
Access Control List | L2~L4 package filtering based on source and destination |
MAC address, IP address, TCP/UDP ports, 802.1p, | |
DSCP, protocol and VLAN ID | |
Time Range Based | |
Security | SSH v1/v2 |
SSL v2/v3/TLSv1 | |
Port Security | |
Broadcast/Multicast/Unknown unicast Storm Control | |
802.1x and Radius Authentication、IP-Mac-Port-VID Binding、ARP Inspection、DHCP Snooping、DoS Defend | |
Management | Web-based GUI and CLI management |
SNMP v1/v2c/v3, compatible with public MIBs and | |
TP-LINK private MIBs | |
RMON (1, 2, 3, 9 groups) | |
CPU Monitoring | |
Port Mirroring | |
Time Setting: SNTP | |
Firmware Upgrade: TFTP & Web | |
System Diagnose: VCT | |
SYSLOG & Public MIBS | |
Certification | FCC, RoHS |
Environment | Operating Temperature: 0℃~40℃ (32℉~104℉); |
Storage Temperature: -40℃~70℃ (-40℉~158℉) | |
Operating Humidity: 10%~90% non-condensing | |
Storage Humidity: 5%~90% non-condensing | |
Warranty | 3 Year |
Note | * Features, Price, Specifications are subject to change without notice. |
