Brand | TP-Link |
Model | SG2210MP |
Color | Black |
Standards and Protocols | IEEE 802.3i |
IEEE 802.3u | |
IEEE 802.3ab | |
IEEE802.3z | |
IEEE 802.3ad | |
IEEE 802.3x | |
IEEE 802.3af | |
IEEE 802.3at | |
IEEE 802.3az | |
IEEE 802.1d | |
IEEE 802.1s | |
IEEE 802.1w | |
IEEE 802.1q | |
IEEE 802.1x | |
IEEE 802.1p | |
Interface | 8× 10/100/1000 Mbps RJ45 Ports, all supporting PoE+ (Auto-Negotiation/Auto MDI/MDIX) |
2× 100/1000 Mbps SFP Slots | |
Network Media | 10BASE-T: UTP/STP category 3, 4, 5 cable (maximum 100m) |
100BASE-TX/1000Base-T: UTP/STP category 5, 5e or above cable (maximum 100m) | |
100BASE-FX: MMF, SMF | |
1000BASE-X: MMF, SMF | |
Fan Quantity | 1 |
PoE Ports (RJ45) | Standard: 802.3at/af compliant |
PoE+ Ports: 8 Ports | |
PoE Power Budget: 150 W* | |
Power Supply | 100-240V AC, 50/60Hz |
Max. Power Consumption | V1: 173.9 W (110 V/60 Hz) (with 150 W PD connected); 12.2 W (110 V/60 Hz) (no PD connected) |
V2: 169.5 W (220 V/50Hz) (with 150 W PD connected) | |
V3: 175.3 W (110 V/60Hz) (with 150 W PD connected) | |
V4: 174.2 W (110V/60Hz) (with 150 W PD connected) | |
Max Heat Dissipation | V1: 41.63 BTU/h (with no PD connected); 539.35 BTU/h (with 150 W PD connected) |
V2: 578.42 BTU/hr (220V/50 Hz) (with 150 W PDconnected) | |
V3: 597.8 BTU/hr (110 V/60 Hz) (with 150 W PD connected) | |
V4: 594.46 BTU/hr (110V/60Hz) (with 150 W PD connected) | |
Switching Capacity | 20 Gbps |
Packet Forwarding Rate | 14.9 Mpps |
Advanced Features | Automatic Device Discovery |
Batch Configuration | |
Batch Firmware Upgrading | |
Intelligent Network Monitoring | |
Abnormal Event Warnings | |
Unified Configuration | |
Reboot Schedule | |
Dimensions | 294 x 180 x 44 mm |
Warranty | 3 Year Brand Warranty |
Note | * Features, Price, Specifications are subject to change without notice. |
