Brand | TP-Link |
Model | CPE610 |
Color | Black |
Processor | Qualcomm 560MHz CPU, MIPS 74Kc |
Memory | 64MB DDR2 RAM,8MB Flash |
Interface | 1 10/100Mbps Shielded Ethernet Port (LAN/POE) |
1 Reset Button | |
Power Supply | Passive Power over Ethernet via LAN (+4,5pins; -7,8pins) |
Voltage range: 16-27VDC | |
Max. Power Consumption | 7.41 W |
Note: When deployed using Passive PoE, the power drawn from the power source will be higher by some amount depending on the length of the connecting cable. | |
Antenna | 23dBi |
Protection | 15KV ESD Protection |
6KV Lightning Protection | |
Wireless Speeds | Up to 300Mbps (40MHz,Dynamic) |
Up to 144.4Mbps (20MHz,Dynamic) | |
Up to 72.2Mbps (10MHz,Dynamic) | |
Up to 36.1Mbps (5MHz,Dynamic) | |
Interfaces | 1 AC Jack with Earth Ground |
1 10/100Mbps Shielded Ethernet Port (Power + Data) | |
1 10/100Mbps Shielded Ethernet Port (Data) | |
Dimensions | 85.8×43.9×29.7 mm |
Warranty | 1 Year Brand Warranty |
Note | * Features, Price, Specifications are subject to change without notice. |
