    Grandstream GWN7830 L3 Managed Switch

    SKU:
    GWN7830
    Be first to review
    ₹ 27,506 ~ ₹ 16,099 41 OFF
    Save GST upto18% on Business purchase
    Wishlist
    Availability: Out of stock
    Notify me when stock is available

    Shop with confidence

    🔒 Secure & Safe Payments
    ✅ 100% Genuine Products
    🎧 Trusted Customer Support
    🚚 Reliable Delivery

    Similar product

    Grandstream GWN7830 L3 Managed Switch


    FEATURES

    • The Grandstream GWN7830 is a Layer 3 managed aggregation network switch designed mainly for medium-sized and large businesses that need a fast, secure, and reliable network. In simple words, it acts like a central point where different parts of a business network can connect and communicate with each other. It is useful for connecting network switches, servers, routers, access points, IP phones, computers, and other network equipment. The GWN7830 provides 2 Gigabit Ethernet ports, 6 Gigabit SFP ports, and 4 10-Gigabit SFP+ ports, giving network administrators several options for connecting both standard Ethernet devices and high-speed fiber links. It offers 48 Gbps of total non-blocking throughput, 96 Gbps switching capacity, and a forwarding rate of 71.424 million packets per second, which helps it handle large amounts of network traffic efficiently.
    • One of the most useful features of the GWN7830 is its Layer 3 routing capability. Unlike a basic network switch that mainly forwards traffic between devices, the GWN7830 can also perform routing functions within the network. It supports IPv4 and IPv6, static routing, and dynamic routing protocols such as RIP, RIPng, OSPF, OSPFv3, and BGP. This makes it suitable for organizations with more complicated network structures, such as offices with multiple departments, buildings, or network segments. Another important feature is VLAN support. VLANs allow a business to separate network traffic into different groups. For example, employees, guests, IP phones, security cameras, and management devices can be placed on separate VLANs even when they use the same physical network infrastructure. The GWN7830 supports up to 4,000 VLANs, along with private VLAN and Voice VLAN features. This makes it easier to organize a large network and improve both security and performance.
    • The GWN7830 also includes Quality of Service (QoS) features. In simple terms, QoS allows the administrator to decide which network traffic should receive higher priority. For example, an organization could give priority to voice calls or video meetings so that they remain smooth even when the network is busy. The switch supports traffic prioritization, queue scheduling, traffic shaping, and rate limiting. Security is another major strength. The switch includes features such as 802.1X authentication, MAC authentication, RADIUS and TACACS+, DHCP snooping, ARP inspection, IP source guard, port security, storm control, DoS protection, and port isolation. These features help prevent unauthorized devices from accessing the network and provide protection against several common network attacks.
    • For networks that use multicast traffic, the GWN7830 supports IGMP and MLD snooping, which can help manage multicast traffic more efficiently. It also supports link aggregation, allowing multiple physical network connections to work together to provide greater capacity or redundancy. Spanning Tree support helps protect the network from problems caused by network loops. The switch can also support stacking, allowing multiple compatible switches to be managed together and providing redundancy between devices.


    SPECIFICATIONS


    Brand

    Grandstream

    Model

    GWN7830

    Color

    Black

    Product type

    Layer 3 Aggregation Managed Switch

    Gigabit Ethernet ports

    2 × 10/100/1000 Mbps

    SFP ports

    6 × 1G SFP

    SFP+ ports

    4 × 10G SFP+

    Total non-blocking throughput

    48 Gbps

    Switching capacity

    96 Gbps

    Forwarding rate

    71.424 Mpps

    Packet buffer

    12 MB

    Network latency

    <4 µs

    MAC addresses

    16K

    VLANs

    4K VLANs

    VLAN interfaces

    16, with 9216-byte MTU

    ARP/NDP

    1K

    Link aggregation

    32 LAG groups

    Routing

    IPv4/IPv6 static routing; RIP/RIPng, OSPF/OSPFv3, BGP

    IPv4 routes

    512

    IPv6 routes

    128

    IGMP Snooping

    IGMPv2/v3, up to 256 groups

    MLD Snooping

    MLDv1/v2, up to 256 groups

    ACL

    2K ACL entries for Ethernet, IPv4 and IPv6

    QoS

    Port priority, priority mapping, SP, WRR, WFQ, SP-WRR, SP-WFQ, traffic shaping, rate limiting

    Security

    802.1X, MAC authentication, RADIUS, TACACS+, DHCP snooping, ARP inspection, IP/IPv6 Source Guard, DoS protection, port security

    Management

    Web UI, CLI, GWN.Cloud/GDMS Networking, GWN Manager

    Console

    1

    Power supply

    30 W integrated power supply

    Surge protection

    ±6 kV power; ±4 kV network ports

    ESD

    ±12 kV contact discharge

    Mounting

    Desktop, wall-mount, rack-mount

    Dimensions

    330 × 175 × 44 mm

    Weight

    1.91 kg

    Operating temperature

    0°C to 45°C

    Operating humidity

    10%–90% RH, non-condensing

    Compliance

    FCC, CE, RCM, IC, UKCA

    Warranty

    3 Year

    Note

    *Price, feature and specifications are subject to change without notice
