    Grandstream GWN7701PA 8-Port Gigabit PoE+ Switch

    SKU:
    GWN7701PA
    Be first to review
    ₹ 12,638 ~ ₹ 7,599 40 OFF
    Earn 75 Gear Coins with this purchase Coins are credited after delivery.
    Log in to view and apply your Gear Coins.
    Save GST upto18% on Business purchase
    Wishlist
    COD Available* | EMI Options Available

    Quantity:
    (1 available)
    Add to cart

    Shop with confidence

    🔒 Secure & Safe Payments
    ✅ 100% Genuine Products
    🎧 Trusted Customer Support
    🚚 Reliable Delivery

    Similar product

    Grandstream GWN7701PA 8-Port Gigabit PoE+ Switch


    FEATURES

    • The Grandstream GWN7701PA is an easy-to-use 8-port Gigabit PoE+ unmanaged network switch designed for businesses and users who need reliable wired connectivity along with convenient power delivery for compatible network devices. It provides a simple way to connect computers, Wi-Fi access points, IP phones, IP cameras, printers, and other Ethernet-enabled equipment in one place. Because it is an unmanaged switch, it does not require complicated configuration or specialist networking knowledge. Users can connect their Ethernet cables, power on the switch, and start using their network with minimal setup. This makes the GWN7701PA particularly suitable for small offices, retail stores, schools, hotels, surveillance installations, and other environments where straightforward networking is important.
    • One of the main advantages of the GWN7701PA is its Gigabit Ethernet connectivity. Gigabit speeds provide fast data communication between connected devices, making the switch suitable for everyday activities such as internet access, file sharing, cloud applications, video conferencing, VoIP communication, and network-based surveillance. The available Ethernet ports provide a convenient way to expand the number of wired devices connected to an existing network. This can be especially useful when a router or another network device does not provide enough ports for all the equipment required in an office or business.
    • The PoE+ functionality is another important feature. Power over Ethernet allows compatible devices to receive both network data and electrical power through a single Ethernet cable. This can make installation much easier because a separate power adapter and nearby electrical outlet may not be required for every compatible device. For example, a business can connect a PoE-compatible Wi-Fi access point, IP phone, or security camera directly to the switch and provide network connectivity and power through the same cable. This helps reduce cable clutter and can make device installation more flexible.
    • The GWN7701PA is designed with plug-and-play operation, making it a practical choice for users who want a simple networking solution. There is no need to manually configure complicated networking settings before using the switch. It can automatically manage communication between connected devices, allowing data to move across the network efficiently.
    • Its combination of Gigabit networking, PoE+ support, multiple Ethernet ports, and simple unmanaged operation makes the GWN7701PA a versatile option for modern network installations. It can help businesses create a cleaner and more organized network while reducing the complexity of installing powered devices. Overall, the Grandstream GWN7701PA is a convenient solution for users who need reliable wired connectivity and an easy way to power compatible network equipment.


    SPECIFICATIONS


    Brand

    Grandstream

    Model

    GWN7701PA

    Color

    Black

    Switch type

    Unmanaged Gigabit Ethernet switch

    Gigabit ports

    8 × RJ45

    Port speed

    10/100/1000 Mbps

    PoE ports

    8

    PoE standard

    IEEE 802.3af / 802.3at

    Maximum PoE per port

    30 W

    Total PoE power budget

    145 W

    PoE priority

    Port 8 → Port 1

    Switching capacity

    16 Gbps

    MAC address table

    8K

    Jumbo frame

    9 KB

    Management

    Unmanaged / Plug-and-play

    Auto-negotiation

    Yes

    Auto MDI/MDIX

    Yes

    Flow control

    IEEE 802.3x

    QoS

    Default Strict Priority

    Storm control

    Broadcast / Multicast / Unicast

    Storm-control limit

    100 Mbps

    LEDs

    Link/Activity, PoE output, Power

    Enclosure

    Metal

    Mounting

    Desktop / Rack-mount

    Power supply

    Internal AC

    Input

    100–240 V AC, 50/60 Hz

    Maximum power supply rating

    150 W

    Base-system consumption

    6.7 W @ 220 V/50 Hz, excluding PoE output

    Operating temperature

    0°C to 40°C

    Storage temperature

    −20°C to 60°C

    Operating humidity

    10%–90%, non-condensing

    Storage humidity

    10%–90%, non-condensing

    Dimensions

    280 × 180 × 44 mm

    Weight

    1.5 kg

    Warranty

    3 Year

    Note

    *Price, feature and specifications are subject to change without notice
