Brand | Avermedia |
Model | AX310 |
Color | Black |
Technical Specifications | Interface: USB 2.0, Type B (Driver Required) |
Mic In: XLR (Balanced) / 6.3mm (Single-End) x 1 | |
Line In: 3.5mm TRS, Stereo x 1 | |
Console In: Optical In (Toslink) x 1 | |
Computer Inputs: Digital Tracks x 3 | |
Headphone Out: 3.5mm TRS, Stereo | |
Line Out: 3.5mm TRS, Stereo | |
Output Mix (Independent Instances): | |
oCreator mix | |
oAudience mix | |
Sampling Rate: Up to 96kHz, 24 bits | |
Microphone Effects: | |
Noise Gate, Reverb, Compressor, Equalizer | |
Frequency Response: 10Hz to 20kHz | |
Dynamic Range: 114 dB | |
Screen Panel: 5" IPS Screen with CTP Touch Panel | |
Widgets: Interactive & Customizable Grid | |
Rotational Encoders: 6 | |
Lighting: RGB | |
Function Buttons: 4 | |
Power Switch: Yes | |
Power Input: Standard 12V DC, Center Negative, 1.5A | |
Power Consumption: <7W | |
Dimensions (W x D x H): | |
Without Stand: 21.7 x 14.5 x 6.1 cm (5.7 x 8.5 x 2.4 in) | |
With Stand: 21.7 x 14.5 x 9.4 cm (5.7 x 8.5 x 3.7 in) | |
Weight: | |
Without Stand: 0.702 kg (24.76 oz) | |
With Stand: 0.847 kg (29.87 oz) | |
- Phantom Power +48V, switchable via AX310 APP | |
- Optical output settings must be set to stereo, AX310 doesn’t support 5.1ch or 7.1ch | |
System Requirements | Windows: Windows 10 or later |
Mac: macOS 10.15 and above | |
Note: Creator Central support Mac M1 Rosetta | |
What's in the box | Live Streamer AX310(AX310) |
Magnetic Kick Stand | |
USB 2.0 type B to Type A Cable (1.8 m / 5.9 ft.) | |
3.5 mm TRS Audio Cable | |
(1.8 m / 5.9 ft.) | |
3.5 mm to 6.3 mm Adapter | |
Power Adapter | |
Quick Guide | |
Warranty | 1 Year |
Note | **Prices, Specifications & Features are subject to change without notice |
