Grandstream GWN7660E Wi-Fi 6 Dual-Band MU-MIMO Indoor Access Point

FEATURE

The Grandstream GWN7660E Wi-Fi 6 Dual-Band MU-MIMO Indoor Access Point is a modern wireless networking solution designed for businesses, offices, schools, hotels, retail stores, and other indoor environments that need fast and dependable Wi-Fi. It combines Wi-Fi 6 technology, dual-band connectivity, MU-MIMO performance, and professional network management features to create a reliable wireless network for multiple users and devices.
The GWN7660E supports the latest Wi-Fi 6 (802.11ax) standard, providing improved efficiency and performance compared with older Wi-Fi technologies. It operates on both 2.4 GHz and 5 GHz frequency bands, allowing different devices to connect according to their performance and coverage requirements. The 2.4 GHz band is useful for wider coverage, while the 5 GHz band is ideal for devices that require faster wireless speeds.
One of the major advantages of this access point is its MU-MIMO technology. It is designed to communicate efficiently with multiple compatible wireless clients at the same time. This makes it suitable for busy environments where employees, students, guests, or customers may have several devices connected simultaneously. Laptops, smartphones, tablets, smart devices, and other wireless equipment can all share the network more efficiently.
The GWN7660E can deliver wireless throughput of up to 3 Gbps, making it suitable for demanding applications such as video conferencing, cloud applications, online meetings, high-quality streaming, file transfers, VoIP communication, and everyday web browsing. Actual speeds may vary depending on connected devices, network traffic, distance, interference, and environmental conditions.
Security is another important feature of the GWN7660E. It includes modern wireless security options designed to help protect users and network resources. Businesses can configure separate wireless networks for employees, guests, and other users, helping improve network organization and access control.
The access point also supports centralized management, making it easier for network administrators to configure, monitor, and maintain multiple compatible Grandstream access points. This can be particularly useful for businesses operating across larger offices, educational facilities, hotels, and commercial buildings.
With a professional indoor design, the GWN7660E can be installed in offices, meeting rooms, classrooms, reception areas, retail environments, and other locations where dependable wireless connectivity is required.
Overall, the Grandstream GWN7660E Wi-Fi 6 Indoor Access Point offers an excellent combination of speed, efficiency, wireless capacity, security, and management. It is a practical choice for organizations looking to upgrade their existing Wi-Fi network and provide a fast, stable connection for many users and devices.

SPECIFICATION

Brand

Grandstream

Model

GWN7660E

Color

White

Wi-Fi Standards

IEEE 802.11 a/b/g/n/ac/ax (Wi‑Fi 6)

Antennas

5 × individual internal antennas (2 × 2.4GHz, 3 × 5GHz)

Antenna Gain

2.4GHz: 4.0 dBi (×2) 5GHz: 5.0 dBi (×3)

Wi-Fi Data Rates

5GHz 802.11ax: 7.3 – 2402 Mbps 802.11ac: 6.5 – 867 Mbps 802.11n: 6.5 – 300 Mbps 802.11a: 6 – 54 Mbps2.4GHz 802.11ax: 7.3 – 573.5 Mbps 802.11n: 6.5 – 300 Mbps 802.11b: 1 – 11 Mbps 802.11g: 6 – 54 Mbps

Frequency Bands

2.4GHz: 2400 – 2483.5 MHz 5GHz: 5150 – 5850 MHz

Channel Bandwidth

2.4GHz: 20 / 40 MHz 5GHz: 20 / 40 / 80 / 160 MHz

Wi-Fi & Security

WEP, WPA/WPA2‑PSK, WPA/WPA2 Enterprise (TKIP/AES), WPA3 Secure boot, digital signatures, certificate lockdown, random default password

MIMO Technology

2×2:2 (2.4GHz) 3×3:2 (5GHz MU‑MIMO)

Coverage Range

Up to 175 meters (varies by environment)

Maximum TX Power

2.4GHz: 24 dBm 5GHz: 24 dBm (varies by country/frequency)

Receiver Sensitivity (2.4GHz)

802.11b: -96 dBm @1 Mbps, -88 dBm @11 Mbps 802.11g: -93 dBm @6 Mbps, -75 dBm @54 Mbps 802.11n 20MHz: -73 dBm @MCS7 802.11n 40MHz: -70 dBm @MCS7 802.11ax 20MHz: -60 dBm @MCS11 802.11ax 40MHz: -58 dBm @MCS11

Receiver Sensitivity (5GHz)

802.11a: -92 dBm @6 Mbps, -74 dBm @54 Mbps 802.11n 20MHz: -73 dBm @MCS7 802.11n 40MHz: -70 dBm @MCS7 802.11ac 20MHz: -67 dBm @MCS8 802.11ac 40MHz: -63 dBm @MCS9 802.11ac 80MHz: -59 dBm @MCS9 802.11ax 20MHz: -60 dBm @MCS11 802.11ax 40MHz: -58 dBm @MCS11 802.11ax 80MHz: -56 dBm @MCS11 802.11ax 160MHz: -52 dBm @MCS11

SSIDs

32 total (16 per radio: 2.4GHz & 5GHz)

Concurrent Clients

256

Network Interfaces

1 × auto‑sensing 10/100/1000 Base‑T Ethernet port

Auxiliary Ports

1 × Reset pinhole 1 × Kensington lock

Mounting Options

Indoor wall mount or ceiling mount (kits included)

LEDs

3 × tri‑color LEDs (device tracking & status indication)

Network Protocols

IPv4, IPv6, 802.1Q, 802.1p, 802.1x, 802.11e/WMM

QoS Features

802.11e/WMM, VLAN, TOS

Network Management

Embedded controller (manage up to 50 APs) GWN.Cloud (free, unlimited APs) GWN Manager (up to 3,000 APs)

Power & Efficiency

PoE 802.3af/802.3at Max Power Consumption: 12.95W

Environmental Conditions

Operating: 0°C – 50°C Storage: -10°C – 60°C Humidity: 10% – 90% (non‑condensing)

Physical Dimensions

Unit: 180.4 × 180.4 × 40.8 mm (TBD), 385 g Package: 228.5 × 220 × 79 mm (TBD), 630 g

Package Contents

GWN7660E Wireless AP, Mounting Kits, Quick Start Guide

Compliance

FCC, CE, RCM, IC

Warranty

3 Year

Note

*Features, Price and Specifications are subject to change without notice.
