Brand | Gigabyte |
Model | B650 AORUS ELITE AX ICE |
Color | White |
Platform | AMD |
Socket | AM5 |
Cpu Type | Ryzen 9000,Ryzen 8000,Ryzen 7000 |
Chipset | B650 |
Memory Speed | up to 8000 |
Max Memory Support | 256 GB |
Supported Memory Type | DDR5 |
Channel Supported | Dual Channel |
Memory Feature | Support for non-ECC Un-buffered DIMM 1Rx8/2Rx8/1Rx16 memory modules |
Support for AMD EXtended Profiles for Overclocking (AMD EXPO) and Extreme Memory Profile (XMP) memory module | |
(The CPU and memory configuration may affect the supported memory types, data rate (speed), and number of DRAM modules, please refer to "Memory Support List" for more information.) | |
Graphics Port | 1 x DisplayPort,1 x HDMI |
Expansion Slots | 1 x PCI Express x16 slot (PCIEX16), integrated in the CPU: |
- AMD Ryzen™ 7000 Series Processors/ Ryzen™ 9000 Series Processors support PCIe 4.0 x16 mode | |
- AMD Ryzen™ 8000 Series-Phoenix 1 Processors support PCIe 4.0 x8 mode | |
- AMD Ryzen™ 8000 Series-Phoenix 2 Processors support PCIe 4.0 x4 mode | |
* The PCIEX16 slot can only support a graphics card or an NVMe SSD. If only one graphics card is to be installed, be sure to install it in the PCIEX16 slot. | |
Chipset: | |
- 2 x PCI Express x16 slots, supporting PCIe 3.0 and running at x1 (PCIEX1_1/2) | |
Wireless Networking | WiFi 6E,Bluetooth 5.3 |
Back Panel I/O Ports | 1 x Q-Flash Plus button |
2 x antenna connectors (2T2R) | |
1 x DisplayPort | |
1 x HDMI port | |
1 x USB Type-C® port, with USB 3.2 Gen 2 support | |
2 x USB 3.2 Gen 2 Type-A ports (red) | |
5 x USB 3.2 Gen 1 ports | |
4 x USB 2.0/1.1 ports | |
1 x RJ-45 port | |
3 x audio jacks | |
Internal I/O Connector | 1 x 24-pin ATX main power connector |
1 x 8-pin ATX 12V power connector | |
1 x 4-pin ATX 12V power connector | |
1 x CPU fan header | |
1 x CPU fan/water cooling pump header | |
3 x system fan headers | |
1 x system fan/water cooling pump header | |
3 x addressable RGB Gen2 LED strip headers | |
1 x RGB LED strip header | |
3 x M.2 Socket 3 connectors | |
4 x SATA 6Gb/s connectors | |
1 x front panel header | |
1 x front panel audio header | |
1 x USB Type-C® header, with USB 3.2 Gen 2x2 support | |
1 x USB 3.2 Gen 1 header | |
2 x USB 2.0/1.1 headers | |
1 x Trusted Platform Module header (For the GC-TPM2.0 SPI/GC-TPM2.0 SPI 2.0/GC-TPM2.0 SPI V2 module only) | |
1 x reset button | |
1 x reset jumper | |
1 x Clear CMOS jumper | |
Form Factor | ATX |
Warranty | 3 Year |
Note | *Features, Price, Specifications are subject to change without notice. |
