Ubiquiti USW-Pro-Max-16-PoE 16-Port 180W PoE Switch

FEATURES

The Ubiquiti USW-Pro-Max-16-PoE is a powerful and flexible managed network switch designed for modern home, office, business, and professional UniFi network installations. It provides multiple Ethernet ports for connecting computers, access points, security cameras, VoIP phones, and other network devices while also delivering power directly through compatible Ethernet cables.
The switch offers a total of 16 Ethernet ports, including 12 GbE PoE+ ports and 4 2.5GbE PoE++ ports. This combination provides flexibility for both standard Gigabit devices and newer high-speed equipment that benefits from faster network connections.
With a generous 180W total PoE power budget, the switch can power several compatible PoE devices without requiring separate power adapters for each device. The PoE+ ports can provide up to 32W per port, while the PoE++ ports can provide up to 64W per port when supported by the connected equipment.
For high-speed network expansion, the switch includes two 10G SFP+ ports. These ports can be used for high-bandwidth uplinks to another switch, server, router, or network storage system, helping reduce network bottlenecks.
The USW-Pro-Max-16-PoE is a managed switch, allowing users to configure and monitor their network through the UniFi Network platform. This provides convenient control over connected devices, network traffic, VLANs, port settings, and other network functions from a centralized interface.
Another useful feature is Etherlighting, which provides visual port identification and network status information, making it easier to identify connected devices and troubleshoot network connections.
Its compact 1U-friendly design allows it to be used in a rack, on a desktop, or mounted on a wall, depending on the installation requirements. The switch also includes a small 1.3-inch LCM display for convenient device information and status monitoring.
Overall, the USW-Pro-Max-16-PoE combines high-speed networking, PoE power delivery, 10G uplinks, centralized UniFi management, and practical installation options in one reliable network switch.

SPECIFICATIONS

Brand

Ubiquiti

Model

USW-Pro-Max-16-PoE

Color

Grey

Dimensions

325.1 x 160 x 43.7 mm (12.8 x 6.3 x 1.7")

Port Layout

1 GbE RJ45: 12 (All PoE+) 2.5 GbE RJ45: 4 (All PoE++) 10G SFP+: 2

Max. PoE Output

Up to PoE++

Total PoE Availability

180W

Layer 3

✓

Form Factor

Rack mount (1U), desktop, wall

Etherlighting™

✓

Switching Capacity

84 Gbps

Total Non-Blocking Throughput

42 Gbps

Forwarding Rate

62 Mpps

Supported VLANs

100000%

MAC Address Table Size

16,000

L3 Table Size

ARP Entries: 6,000 IPv4 Routes: 512

Packet Buffer Size

1.5 MB

Layer 3 Features

DHCP Server (Local Networks), DHCP Relay, Inter-VLAN Routing, Static Routing

Layer 2 Features

LACP Port Aggregation, STP & RSTP, QoS (DSCP), Pro AV Profiles, Advanced IGMP Configuration, IGMP Snooping, 802.1X Control, MAC-Based ACLs & Device Isolation, DHCP Snooping & Guarding, Egress Rate Limit, Flow Control, Storm Control, Multicast & Broadcast Rate Limiting, MAC Address Blocking, IP-Based ACLs & Network Isolation, MAC-Based Port Restriction, Port Isolation, Port Mirroring, Jumbo Frames, LLDP-MED, Voice VLAN, Loop Protection

PoE Ports

PoE+: 12 PoE++: 4

Max. PoE Wattage per Port by PSE

PoE: 15.4W PoE+: 32W PoE++: 64W

Max. Power Consumption

25W (Excluding PoE Output) 210W (Including PoE Output)

Power Method

AC Adapter

Power Input Method

AC input

Power Supply

AC/DC, external, 210W

Supported Voltage Range

50–54V DC

Management

Ethernet, AR

Heat Dissipation

102.36 BTU/hr (Excluding PoE Output)

Weight

2.1 kg (4.6 lb)

Enclosure Material

SGCC steel

LCM Display

1.3" touchscreen

Operating Temperature

-5°C to 40°C (23°F to 104°F)

Operating Humidity

10–90% noncondensing

Certifications

CE, FCC, IC

Etherlighting™

Ethernet, SFP+

Warranty

1 Year

Note

*Price, feature and specifications are subject to change without notice
