Ubiquiti POE-24-12W 24V 0.5A Passive PoE Injector Adapter

FEATURES

The Ubiquiti POE-24-12W-EU is a compact and reliable 24V passive PoE injector designed to provide power and network connectivity to compatible Ubiquiti devices through a single Ethernet cable. It is a practical solution for installations where a PoE switch is not available but a compatible network device needs to receive power through its Ethernet connection.
The adapter provides 24V DC at 0.5A, delivering up to 12W of power to supported devices. This makes it suitable for compatible Ubiquiti outdoor CPEs, wireless access points, antennas, and other networking equipment that supports 24V passive PoE.
The POE-24-12W features a 10/100 Mbps Ethernet connection, allowing network data and electrical power to be delivered through the same Ethernet cable. This helps simplify installations by reducing the number of cables required between the network equipment and the powered device.
Its compact and lightweight design makes the adapter easy to install and convenient to use in homes, offices, network cabinets, communication rooms, and outdoor wireless installations. It can be positioned near the network switch or router while the Ethernet cable carries power to the compatible remote device.
The adapter is designed with passive PoE technology, which means it supplies power directly through the Ethernet cable rather than negotiating power with the connected device. Therefore, it should only be used with equipment that specifically supports 24V passive PoE.
The POE-24-12W also incorporates protection features designed to help safeguard the adapter and connected equipment against common electrical issues. Its simple plug-and-play style makes it easy to deploy without complicated configuration or software.
Overall, the Ubiquiti POE-24-12W-EU is a convenient and cost-effective power solution for compatible Ubiquiti networking devices. With its 24V/0.5A output, 12W power capacity, 10/100 Ethernet, passive PoE technology, compact design, and easy installation, it is well suited for a variety of home, office, and outdoor networking applications.

SPECIFICATIONS

Brand

Ubiquiti

Model

POE-24-12W-EU

Color

White

Output Voltage

24V DC

Output Current

0.5A

Maximum Power

12W

Ethernet Port

10/100 Mbps

Gigabit LAN

Powering Method

2-Pair Passive PoE

Power Pins

Pins 4, 5 (+) / Pins 7, 8 (-)

Input Voltage

100–240V AC

Input Frequency

50/60 Hz

Input Current

0.3A @ 120V / 0.2A @ 240V

Efficiency

75%+

Output Ripple

1% maximum

Switching Frequency

50 kHz

Line Regulation

≤ 3%

Load Regulation

≤ 5%

Dimensions

87 × 44 × 29 mm

Weight

92 g

Operating Temperature

0°C to 40°C

Storage Temperature

-30°C to 70°C

Operating Humidity

35–95%, non-condensing

AC Connector

IEC-320 C6

Ethernet Connector

Shielded RJ45

LAN Activity Indicator

Remote Reset

Yes

Reset Button

Yes

Surge Protection

Differential and common-mode

Clamping Protection

11V data / 60V power

Maximum Surge Discharge

1500A (8/20 μs)

Peak Pulse Current

36A (10/1000 μs)

Response Time

<1 ns

Certifications

CE, FCC, IC, UL

NDAA Compliant

Yes

Warranty

1 Year

Note
