Workstation-Grade Design: Designed for powerful professional, workstation and enthusiast PC systems.
0.8mm SPCC Construction: Features a strong and durable 0.8mm SPCC steel chassis for long-lasting reliability.
Dual-Function GPU Holder: Helps reduce GPU sag while supporting single or dual graphics card configurations.
420mm GPU Clearance: Provides ample space for large, high-end graphics cards up to 420mm in length.
480mm Radiator Support: Supports large liquid-cooling radiators up to 480mm for advanced cooling configurations.
5 × 120mm PWM Fans Included: Comes with four front 120mm PWM fans and one rear 120mm PWM fan.
Digital Fan-Speed Display: The rear fan features a digital display for convenient real-time fan-speed monitoring.
9 Expansion Slots: Provides nine expansion slots for multi-GPU and high-performance workstation configurations.
Wide Motherboard Compatibility: Supports EEB, CEB, E-ATX, ATX, Micro-ATX and Mini-ITX motherboard form factors.
High Storage Capacity: Supports up to 4 × 3.5-inch HDDs and 6 × 2.5-inch SSDs for flexible storage expansion.
Fast Connectivity: Includes 2 × USB 3.0 ports and 1 × USB Type-C port for modern device connectivity.
Brand | FSP |
Model | U500-B |
Type | Workstation |
Color | Black |
Material | 0.8mm SPCC |
Motherboard Support | EEB, CEB, E-ATX, ATX, M-ATX, Mini-ITX |
Expansion Slots | 9 |
GPU Support | Up to 420mm |
GPU Holder | Dual-function / fixed bracket design |
CPU Cooler Height | Up to 180mm |
Pre-installed Fans | 4 × 120mm PWM Front + 1 × 120mm PWM Rear |
Rear Fan Feature | Digital fan-speed display |
Front Fan Support | 4 × 120mm or 3 × 140mm |
Top Fan Support | Up to 3 × 120/140mm |
Bottom Fan Support | Up to 3 × 120mm |
Rear Fan Support | 1 × 120/140mm |
Front Radiator Support | 420mm / 480mm |
Top Radiator Support | 360mm |
Maximum Radiator Support | 480mm |
3.5" HDD Support | Up to 4, shared with SSD |
2.5" SSD Support | Up to 6 |
PSU Support | ATX, up to 230mm |
I/O Ports | 2 × USB 3.0, 1 × Type-C |
Dimensions (D × W × H) | 450 × 258 × 568mm |
Net Weight | 10.6kg |
Warranty | 1 Years |
Note | Features, Price, Specifications are subject to change without notice |
